from dataclasses import dataclass
from random import randint, uniform
import cv2
import numpy as np
@dataclass
class node:
"""node class cardinal links"""
# pixel position
x: float
y: float
# used to have setters that asserted object had different ID
# north easth, south, west
n = None
e = None
s = None
w = None
def pos(self):
return (int(self.x), int(self.y))
def __str__(self):
return f'x: {self.x} y: {self.y} n: {type(self.n)} e: {type(self.e)} s: {type(self.s)} w: {type(self.w)}'
@dataclass
class rectangle:
"""nodes to form a rectangle, top left, top right, bottom right, bottom left"""
tl: node
tr: node
br: node
bl: node
def node_average(node1: node, node2: node, weight=.5):
"""create node with weighted average of given node positions"""
return node(node1.x * weight + node2.x * (1-weight),
node1.y * weight + node2.y * (1-weight))
def rectangle_from_dimensions(w: float, h: float, ox: float = 0, oy: float = 0):
"""create initial rectangle from width, height, offset"""
tl, tr, br, bl = node(ox, oy), node(ox+w, oy), node(ox+w, oy+h), node(ox, oy+h)
tl.e, tr.w = tr, tl
tr.s, br.n = br, tr
br.w, bl.e = bl, br
bl.n, tl.s = tl, bl
return rectangle(tl, tr, br, bl)
def vertical_split(rect: rectangle, weight=(.5, .5)):
tl, tr, br, bl = rect.tl, rect.tr, rect.br, rect.bl
weight = uniform(*weight)
mt = node_average(tl, tr, weight=weight) # use the same weight for both to create rectangular images
mb = node_average(bl, br, weight=weight)
# ======== left ========
# iterate down the linked list until pixel height is lower
n1 = tl
while n1.x < mt.x: n1 = n1.e
# if pixel high it the same us present node (prevent multiple nodes in same location)
if n1.x == mt.x:
mt = n1
# insert node in between nodes
else:
mt.e, mt.w = n1, n1.w
n1.w.e, n1.w = mt, mt
# =======================
# ======== right ========
n2 = bl
while n2.x < mb.x: n2 = n2.e
if n2.x == bl.x:
bl = n2
else:
mb.e, mb.w = n2, n2.w
n2.w.e, n2.w = mb, mb
# =======================
mt.s, mb.n = mb, mt
return rectangle(tl, mt, mb, bl), rectangle(mt, tr, br, mb)
def horizontal_split(rect: rectangle, weight=(.5, .5)):
tl, tr, br, bl = rect.tl, rect.tr, rect.br, rect.bl
weight = uniform(*weight)
ml = node_average(tl, bl, weight=weight)
mr = node_average(tr, br, weight=weight)
# top
n1 = tl
while n1.y < ml.y: n1 = n1.s
if n1.y == ml.y:
ml = n1
else:
ml.s, ml.n = n1, n1.n
n1.n.s, n1.n = ml, ml
# bottom
n2 = tr
while n2.y < mr.y: n2 = n2.s
if n2.y == mr.y:
mr = n2
else:
mr.s, mr.n = n2, n2.n
n2.n.s, n2.n = mr, mr
ml.e, mr.w = mr, ml
return rectangle(tl, tr, mr, ml), rectangle(ml, mr, br, bl)
def random_n_deep(rect: rectangle, n: int, weight=(.5, .5)):
"""recursive rectangle splitting"""
rect1, rect2 = vertical_split(rect, weight=weight) if randint(0, 1) else horizontal_split(rect, weight=weight)
if n > 0:
s1 = random_n_deep(rect1, n-1, weight=weight)
s2 = random_n_deep(rect2, n-1, weight=weight)
return [*s1, *s2]
return rect1, rect2
def draw_rect(canvas, rect: rectangle, color=(0, 0, 0), thickness=1, shrink=0):
"""helper function for drawing rectangles"""
p1, p2, p3, p4 = rect.tl.pos(), rect.tr.pos(), rect.br.pos(), rect.bl.pos()
cv2.line(canvas, p1, p2, color=color, thickness=max(thickness, 1))
cv2.line(canvas, p2, p3, color=color, thickness=max(thickness, 1))
cv2.line(canvas, p3, p4, color=color, thickness=max(thickness, 1))
cv2.line(canvas, p4, p1, color=color, thickness=max(thickness, 1))
# cv2.polylines(canvas, [np.array([p1, p2, p3, p4], dtype=np.int32)], color=color, thickness=min(thickness, 1), isClosed=True)
# p1, p2 = rect.tl.pos(), rect.br.pos()
# p1 = (p1[0] + shrink, p1[1] + shrink)
# p2 = (p2[0] - shrink, p2[1] - shrink)
# cv2.rectangle(canvas, p1, p2, color=color, thickness=thickness)
if __name__ == "__main__":
import time
# white space around image
offset = 50
# image dimensions
aspect = (700, 500)
# generate rectangular slices
rects = random_n_deep(rectangle_from_dimensions(aspect[1], aspect[0], offset, offset), 6, weight=(.40, .60))
# create canvas
canvas = np.ones((aspect[0] + offset*2, aspect[1] + offset*2, 3), dtype=np.uint8) * 255
# # draw filled rectanges
# for rect in rects:
# color = list(map(int, (uniform(0, 255), uniform(0, 255), uniform(0, 255))))
# colors = [(0, 0, 200), (0, 200, 200), (200, 0, 0), (255, 255, 255)]
# # draw_rect(canvas, rect, color=colors[min(randint(0, 4), 3)], thickness=-1)
# draw_rect(canvas, rect, color=color, thickness=-1)
# draw shrunk outlines
for rect in rects:
color = list(map(int, (uniform(0, 255), uniform(0, 255), uniform(0, 255))))
draw_rect(canvas, rect, color=color, thickness=5, shrink=3)
# display image
cv2.imshow('image', canvas)
q = cv2.waitKey(0)
# save if 's' pressed
if q == ord('s'):
cv2.imwrite(f"./image_{str(time.time()).replace('.', '')}.png", canvas)
|
